0.96" I2C IIC SPI Serial 128X64 OLED LCD Display SSD1306 for Arduino 51 STM32 White/Blue/Blue+Yellow Optional
0.96" I2C IIC SPI Serial 128X64 OLED LCD Display SSD1306 for Arduino 51 STM32 White/Blue/Blue+Yellow Optional
SKU:030072SU
Regular price
$10.99
- guaranteeQuality checked
- Special gift cardsSpecial gift cards
- Free return Within 60 days
- Consultancy86-0755-85201155
Features:
- Super High Brightness (Adjustable)
- Super High Contrast (Adjustable)
- Embedded Driver/Controller
- Font Colors: White/Blue/Blue Yellow Optional
- Drive Duty: 1/64 Duty
- Pixels: 128x64
- Panel Size: 26.70mm x 19.26mm x 1.85mm
- Active Area: 21.74mm x 11.2mm
- Pixel Size: 0.15mm x 0.15mm
- Needn't backlight, the display unit can self-luminous
- High resolution: 128 * 64
- Viewing angle:> 160 °
- Supports many control chip: Fully compatible with Arduino, 51 Series, MSP430 Series, STM32 / 2, CSR IC, etc.
- Ultra-low power consumption: full screen lit 0.08W
- Voltage: 3V ~ 5V DC
- Working Temperature: -30 ℃ ~ 70 ℃
- Module Size: 27.0MM * 27.0MM * 4.1MM
- I2C/IIC Interface, need 2 IO only.
- Driver IC: SSD1306
- 1*Blue/White/Blue+Yellow 0.96" I2C IIC SPI Serial 128X64 OLED LCD Display
