140PCS 14valuesX10pcs Mylar Film Capacitor Assorted Kit 630V 2J102J~2J683J 1nF~68nF Polyester film Capacitor 2J222J 2J152J
140PCS 14valuesX10pcs Mylar Film Capacitor Assorted Kit 630V 2J102J~2J683J 1nF~68nF Polyester film Capacitor 2J222J 2J152J
SKU:XD0015
Regular price
$9.99
![]()
- guaranteeQuality checked
- Special gift cardsSpecial gift cards
- Free return Within 60 days
- Consultancy86-0755-85201155
First, the parameters:
Model: polyester capacitor
Nominal capacity: Polyester capacitor package Tolerance: 5 (%)
Dielectric material: Thin film Equivalent series resistance (ESR): 0
Rating: High
Termination Type: Plug-in Lead Type: Codirectional Lead Distance: 2.54
Mounting Type: In-line Item No.: Polyester Capacitor Package: In-line
Rated voltage range: 63-630V.
Loss tangent: 0.3-0.7.
Operating temperature: -55 ° C to 125 ° C.
Temperature coefficient: +200 +600ppm
Second, the packaging model and quantity:
14 specifications each 10 total 140 630V polyester capacitor package
2J102J 630V 1NF 10pcs 2J152J 630V 1.5NF 10pcs
2J222J 630V 2.2NF 10pcs 2J272J 630V 2.7NF 10pcs
2J332J 630V 3.3NF 10pcs 2J472J 630V 4.7NF 10pcs
2J562J 630V 5.6NF 10pcs 2J682J 630V 6.8NF 10pcs
2J822J 630V 8.2NF 10pcs 2J103J 630V 10NF 10pcs
2J223J 630V 22NF 10pcs 2J333J 630V 33NF 10pcs
2J473J 630V 47NF 10pcs 2J683J 630V 68NF 10pcs
Third, the feature description:
Polyester Capacitor refers to the use of two pieces of metal foil as electrodes, sandwiched in a very thin insulating medium, rolled into a cylindrical or flat cylindrical core, the medium is polyester, polyester film capacitor, high dielectric constant, volume Small, large capacity, good stability, suitable for bypass capacitors.
Outstanding advantages: film capacitor accuracy, loss angle, insulation resistance, temperature characteristics, reliability and adaptability to the environment are better than electrolytic capacitors, ceramic capacitors and two capacitors.
Outstanding disadvantages: the ratio of capacity to price and volume to volume ratio are greater than the above two capacitors.
Fourth, parameter identification:
Foreign capacitor withstand voltage values are usually expressed in letters, and the common code and cardinality are:
A: 1.0; B: 1.25; C: 1.6; D: 2.0; E: 2.5; F: 3.15; G4.0;
H: 5.0; J: 6.3; K: 8.0; Z: 9.0;
The number preceding the letter indicates a power of 10, such as 2A, which is 102*1.0=100V, 2C is 102*1.6=160V, and so on.
The letter after the withstand voltage indicates the capacitance capacity in pF.
For example, 823 indicates a capacity of 82*10^3=82000Pf, 224 indicates 22*104=220000pf=0.22μF; the last letter indicates accuracy, such as J indicates a capacity tolerance of ±5% and the like.
Typical example of capacitance identification: 2A823J is 82000Pf±5%, withstand voltage 100V
