40W50WX2 Stereo Bluetooth Digital Power Amplifier Board 12V/24V2.0 Dual Channel Knob Volume Adjustment Switch

40W50WX2 Stereo Bluetooth Digital Power Amplifier Board 12V/24V2.0 Dual Channel Knob Volume Adjustment Switch

SKU:XF0078
Regular price $10.99

Product parameter:
  • Product name: 50W+50W stereo bluetooth digital power amplifier
  • Product model: XY-AP50L
  • Supply voltage: DC: 5-24V (the higher the voltage, the greater the output power)
  • Bluetooth version: 5.0
  • Transmission distance: 15 meters (unobstructed)
  • Number of channels: left and right dual channels (stereo)
  • Adapted speaker: 30W-200W4Ω8Ω16Ω
  • Protection mechanism: power supply reverse connection protection, short circuit protection, self-recovery overheating protection
  • Note: The output power of the power supply must be greater than the output power of the amplifier, otherwise it will affect the sound quality
  • 12V→8Ω/15W+15W, 4Ω/20W+20W
  • 15V→8Ω/18W+18W, 4Ω/more than 30W+30W
  • 19V-→8Ω/32W+32W, 4Ω/more than 45W+45W
  • 24V→8Ω/40W+40W, 4Ω/more than 50W+50W
Precautions for use:
  • Use the power amplifier board as far away as possible from the WIFI signal (router)
  • The recommended power supply voltage is DC 5~24V, if it exceeds 26V, the chip will burn.
  • The power supply current is recommended to exceed 2A.
  • The speaker cable should not be too long, and ensure that it is suitable within 1 meter
  • Pay attention to static electricity protection. Discharge the static electricity on your hands before touching the power amplifier board to avoid static electricity
  • If the chip is broken down, the Bluetooth chip is more sensitive to static electricity.
  •  It is recommended to adapt the speaker with a rated power of 40W and above to prevent the speaker from heating and burning
trust seal
  • guaranteeQuality checked
  • Special gift cardsSpecial gift cards
  • Free return Within 60 days
  • Consultancy86-0755-85201155
Product parameter:
  • Product name: 50W+50W stereo bluetooth digital power amplifier
  • Product model: XY-AP50L
  • Supply voltage: DC: 5-24V (the higher the voltage, the greater the output power)
  • Bluetooth version: 5.0
  • Transmission distance: 15 meters (unobstructed)
  • Number of channels: left and right dual channels (stereo)
  • Adapted speaker: 30W-200W4Ω8Ω16Ω
  • Protection mechanism: power supply reverse connection protection, short circuit protection, self-recovery overheating protection
  • Note: The output power of the power supply must be greater than the output power of the amplifier, otherwise it will affect the sound quality
  • 12V→8Ω/15W+15W, 4Ω/20W+20W
  • 15V→8Ω/18W+18W, 4Ω/more than 30W+30W
  • 19V-→8Ω/32W+32W, 4Ω/more than 45W+45W
  • 24V→8Ω/40W+40W, 4Ω/more than 50W+50W
Precautions for use:
  • Use the power amplifier board as far away as possible from the WIFI signal (router)
  • The recommended power supply voltage is DC 5~24V, if it exceeds 26V, the chip will burn.
  • The power supply current is recommended to exceed 2A.
  • The speaker cable should not be too long, and ensure that it is suitable within 1 meter
  • Pay attention to static electricity protection. Discharge the static electricity on your hands before touching the power amplifier board to avoid static electricity
  • If the chip is broken down, the Bluetooth chip is more sensitive to static electricity.
  •  It is recommended to adapt the speaker with a rated power of 40W and above to prevent the speaker from heating and burning
