DC 5-36V to 1.3-32V XL4016 Voltmeter Ammeter Regulator Buck Step Down Module
DC 5-36V to 1.3-32V XL4016 Voltmeter Ammeter Regulator Buck Step Down Module
SKU:012709
Regular price
$14.99
- guaranteeQuality checked
- Special gift cardsSpecial gift cards
- Free return Within 60 days
- Consultancy86-0755-85201155
Description:
- Built in XL4016 Chip.
- Regulating potentiometer (damping)
- Aluminum alloy black coating radiator. (long term use of recommended current should not exceed 5A. If more than 5A, you need to use fan assisted cooling)
- Each part comes from the brand, the quality is guaranteed.
- Large inductance of copper core. Inductive coil action on AC finite current. It can be composed of high or low pass filter with resistor or capacitor. Phase shifting circuit and resonant electric. It can connect DC and resistance AC.
- Dual layer high density glass fiber circuit board for 1.6mm military quality. The circuit board is not only thick, but also of high density. And after a long period of use, there will be no edge delamination bulge phenomenon.
- Product name: Digital DC regulator board
- Pressure regulation mode: PWM modulation
- Input voltage: DC 5-36V
- Output voltage: DC 1.25--36V
- Maximum current: 8A (long term recommendation 5A)
- Maximum power: 200W
- Conversion efficiency: 0.94
- Switching frequency: 180KHz
- Appearance size: 78x63mm/3.07x2.48"
- Other functions: Short circuit protection current measurement
- Electronic maintenance application
- Rectifier bridge application
- Power application
- 1PC × DC-DC 5-36V 1.3-32V XL4016 Voltage Regulator LED Voltmeter Ammeter Buck Step Down Power Supply Module
