RXC6 433Mhz Superheterodyne Wireless Receiver PT2262 Code Steady for Arduino/AVR Diy Module Electronic Diy Kit Pcb Board

RXC6 433Mhz Superheterodyne Wireless Receiver PT2262 Code Steady for Arduino/AVR Diy Module Electronic Diy Kit Pcb Board

SKU:011276
Regular price $4.99






Characteristic:
  (1) receiver sensitivity reach -110dBm;
  (2) Operating frequency: 433.92MHz;
  (3) Power supply voltage input range: 3.3V-5.5V;
  (4) Low power consumption, 5.0V @ 433.92MHz, 3.8-4.1mA; 5.0V @ 315MHz,2.5-2.8mA; sustained data transfer rate to 2.4K of (Manchester encoding)
  (5) good selectivity and spurious radiation suppression, and easy through CE / Fcc international certification;
  (6) Good local oscillator radiation suppression, multiple receiver modules to work together (ie, more than single income) and will not interfere with each other, used together does not affect the receiving distance.
  (7) Temperature range: -30-85 ?, also can work even in harsh ambient temperature;
  (8) size:28*12.5*5.00 (mm).

Mode Set:
    1.T1,T2 not short:Self-reset mode
    2.T2 short:Self-locking mode
    3.T1 shot:Interlock mode


  Package Included :

        1 x   RXC6 433Mhz Superheterodyne Wireless Receiver PT2262 Code Steady for Arduino/AVR











































trust seal
  • guaranteeQuality checked
  • Special gift cardsSpecial gift cards
  • Free return Within 60 days
  • Consultancy86-0755-85201155






Characteristic:
  (1) receiver sensitivity reach -110dBm;
  (2) Operating frequency: 433.92MHz;
  (3) Power supply voltage input range: 3.3V-5.5V;
  (4) Low power consumption, 5.0V @ 433.92MHz, 3.8-4.1mA; 5.0V @ 315MHz,2.5-2.8mA; sustained data transfer rate to 2.4K of (Manchester encoding)
  (5) good selectivity and spurious radiation suppression, and easy through CE / Fcc international certification;
  (6) Good local oscillator radiation suppression, multiple receiver modules to work together (ie, more than single income) and will not interfere with each other, used together does not affect the receiving distance.
  (7) Temperature range: -30-85 ?, also can work even in harsh ambient temperature;
  (8) size:28*12.5*5.00 (mm).

Mode Set:
    1.T1,T2 not short:Self-reset mode
    2.T2 short:Self-locking mode
    3.T1 shot:Interlock mode


  Package Included :

        1 x   RXC6 433Mhz Superheterodyne Wireless Receiver PT2262 Code Steady for Arduino/AVR
